Inventables Inventables X-Carve 1000mm CNC Machine

The Inventables X-Carve 1000mm Bundle is designed for makers looking to start their CNC journey with precision, reliability, and versatility. A Modular Waste Board, Makita Variable Speed Compact Router, dust collection system, tool kit, and more are included for a comprehensive CNC system.

  • Intuitive operation for beginners and small businesses
  • Carve wood, plastic, and soft metals
  • Cut materials up to 37" wide
  • Work Area: 29.5in x 29.5in x 4.5in
Inventables X-Carve Machines
List Price: $2,599.00
Price: $1,395.00
Price: $...
Order Now: Ships calculating... MatterHackers Shipping Truck Ships via Freight - some fees may apply.
This item takes longer to ship due to its size and/or weight.
Qty
loading...
Available Add-ons (6)
Price: $599.00
Price: $410.00 View Addon »
Price: $199.99 $149.99 View Addon »
Price: $52.63 View Addon »
Price: $51.03 View Addon »
Price: $91.97 $90.00 View Addon »
Show More Addons
Product No. M-MY5-K70W

INVENTABLES X-CARVE

START YOUR CNC JOURNEY EASILY AND QUICKLY

The Inventables X-Carve Bundle is designed for makers looking to start their CNC journey with unrivaled precision, reliability, and versatility. Effortlessly create small signs, home decor, art, and more in wood, plastic, and soft metals.

Key Features of the Inventables X-Carve 1000mm:

  • Intuitive operation for beginners and small businesses
  • Uses quality materials for a reliable, sturdy CNC machine
  • Carve standard materials like wood, plastic, and soft metals
  • Included Modular Waste Board offers versatile clamping options
  • Makita Variable Speed Compact Router Included
  • Supported by Easel Pro for easy and quick learning (OPTIONAL ADD-ON)



The Reliable Desktop CNC Machine

The Inventables X-Carve 1000mm is an excellent option for makers entering the world of CNC. Capable of carving wood, plastics, and materials like aluminum, Corian, and linoleum up to 37 inches wide, the X Carve, allows you to go from design to completed project in less time than ever before.

  • Work Area: 29.5 in x 29.5 in x 4.5 in
  • Machine Footprint: 41 in x 52 in x 22 in
  • Maximum passthrough sheet width: 37 in
  • Weight: Approx 100lbs
Inventables X Carve CNC Machine carving into multiple types of materials for reliable, consistent application

Design, carve, and sell with Inventables comprehensive CNC system

Design, Carve, Sell

The X-Carve is not just a machine, but an ecosystem for your CNC needs. Powered by Easel, Inventables' web-based design platform, it offers a vast design library, easy import options, and seamless customization—perfect for makers starting their journey or business.

  • 1-Year or 3-Years of Easel Pro available as an optional add-on.
  • No past CNC, CAD, or CAM experience required to start.
  • Select designs from the Pro Design Library or create your own!

Create a Wide Variety of Different Projects

The X-Carve is equipped to help you create a wide variety of different projects. Its modular wasteboard includes T-slot and threaded inserts giving you more clamping options and the passthrough sheet width allows you to work with sheets larger than the standard work area.

  • Easy-to-use Dust Collection System keeps your work area clean of debris and dust
  • Dedicated carving bits for Fine Detail, Soft Metals and V-Carving
  • Makita Router allows you to experiment with different feed rates and depths of cut
Multiple wooden projects carved on the Inventables X Carve CNC Machine

Close up of the Inventables XCarve CNC Machine finely carving letters into into wood for a sign

Built for Rigidity and Precision

The Z-axis on the Inventables X-Carve is built with precision linear bearings and a direct drive Acme lead screw for high performance, high reliability, and low maintenance.

  • US Spindle: Makita rt0701c
  • Horsepower: 1.25hp
  • No Load Speed: 10,000-30,000 RPM controlled by dial
  • Bits: ¼ in and ⅛ in collets included

What are the Differences Between the Inventables X-Carve and X-Carve Pro?

Inventables XCarve CNC Machine Inventables XCarve Pro CNC Machine
Model X Carve X Carve Pro
Price $1395 $4250/ $5995
Cutting Area 29.5 x 29.5in2 48 x 24in2 / 48 x 48in2
Machine Footprint 41 x 52 x 22in3 65.75 x 31.6 x 25in3 /
65.75 x 55.75 x 25in3
Machine Weight ~100 lbs ~275lbs / ~300 lbs
Optimized for • Beginner makers
• Small business startups
• Aspiring established businesses
• Established businesses scaling
   up production
Project Applications Small Signs, Home Decor, Art Furniture, Cabinets, Built-Ins,
Large Signs
Accuracy ~0.005" ~0.001"
Spindle 1.25hp (800W)
Makita router
2hp (1,500W) spindle run by
a pre-programmed VFD
Spindle RPM Range 10,000 - 30,000 RPM 12,000 - 24,000 RPM
Gantry Belt drive with Delrin V-wheels X
and Y Precision linear bearings
with acme leadscrew Z
High-precision 25mm ball screws
on X and Y axes linear guides on
all axes, 2x on X and Z axes
Assembly

Unassembled Kit

Semi-Assembled Kit
(Gantry is pre-assembled)
Assembly Time 16 - 18 hrs 2 hrs

What Materials Can I Carve with the Inventables X-Carve?

The X-Carve's powerful Makita Router is engineered to provide users with high-level precision and performance. With a full 1-1/4 maximum horsepower, the RT0701C is engineered for a range of precision routing applications. Capable of accepting 1/4" and 1/8" router bits users are encouraged to explore multiple material options.

Material options include:

Wood & Wood Composites Plastics Non-Ferrous Metals1
Plywood HDPE Aluminum
Hardwoods Delrin®️ Brass
Softwoods Polycarbonate Copper
MDF Acrylic
Corian®️

1 For optimal results in aluminum and non-ferrous metals, lubrication and tools specifically designed for metals are required.

Note: In order to achieve optimal results when carving, proper cut settings and chip removal are required. Inventables continues to test and refine cut settings for materials and will provide updated recommendations in Easel when available.




What's Included with the Inventables X-Carve Bundle?

Upgraded X-Carve
Components
Upgraded NEMA Cable
Subassembly
Upgraded Belt and
Motor Kit
Upgrade Inventables X Carve components for the Inventables X Carve 1000 CNC machine
Upgraded Wasteboard Clamp Set Upgraded Z-Axis Kit
Dust Control System X-Controller Z-Probe
Rail Kit Side Board Drag Chain
Homing Switches Digital Calipers Tool Kit
Makita Router Makita Spindle Mount Precision 1/8" Collet
Makita Router which is compatible with the Inventables XCarve CNC machine Makita Spindle Mount for the Inventables X Carve CNC Machine

What are the Technical Specifications for the Inventables X-Carve 1000mm?

Technical Specifications

  • Machine Footprint: 41 in x 52 in x 22 in
  • Work Area: 29.5in x 29.5in x 4.5in
  • Maximum Passthrough Sheet Width: 37in
  • Weight: Approx 100lbs

Finish:

  • Finish: Anodized Aluminum

Spindle & Cooling:

  • Spindle: Makita RT0701C
    • Amps:
    • Horsepower: 1-1/4HP
    • No load speed: 10,000-30,000 RPM controlled by dial
    • Bits: ¼ in and ⅛ in collets included
    • Z-Axis: Precision linear guides and direct drive acme leadscrew for high performance, high reliability, and low maintenance

Gantry:

  • Belts: 9mm wide 3GT
  • Stepper Motors (3): NEMA-23
  • Assembly Time: Approx 16 hours with detailed instructions and training to have you feeling like an XC expert when you finish

Dust Control:

  • Dust Control: Included in fully-loaded package
  • Vacuum: Not Included

Motion Control:

  • X-Controller included
  • 4A stepper motor drivers
  • 110-240V (switchable)

Software: (OPTIONAL ADD-ON)

  • Control Software: Easel Pro


FAQ


Hardware


What is the footprint of the X-Carve?

41 x 52 x 22in3

What is the weight of the X-Carve?

Approx. 100lbs

Is there an expander kit to turn my X-Carve into an X-Carve Pro?

Currently there is no offering for an expander kit to turn your X-Carve into an X-Carve Pro.

  • The X-Carve and X-Carve Pro are two very different CNC machines. The X-Carve uses a router and belt drive system, while the X-Carve Pro has an included spindle and uses ball screws and linear guides. While it’s not possible to expand your X-Carve to an X-Carve Pro, many customers are looking forward to running both machines out of their shop.

What is the maximum width sheet material that can pass through the X-Carve?

The maximum width that sheets can pass through is 37 inches.

Can I carve metal with it?

You can carve aluminum and other non-ferrous metals.

  • For optimal results in aluminum and non-ferrous metals, lubrication and tools specifically designed for metals are required.

What materials can I carve?

The Inventables X-Carve can carve plywood, hardwoods, softwoods, and MDF. It can carve plastics, including HDPE, Delrin®️, polycarbonate, acrylic, and Corian®️.* It can also carve Non-ferrous metals, including aluminum, brass, copper, etc.

  • For optimal results in aluminum and non-ferrous metals, lubrication and tools specifically designed for metals are required. *In order to achieve optimal results when carving, proper cut settings and chip removal are required. Inventables continues to test and refine cut settings for materials and will provide updated recommendations in Easel when available.

Can I attach a laser?

Inventables does not have any plans down the line to support anything besides a router head for X-Carve.

  • There are some people making these modifications to their machines but they are considered unsupported upgrades, are not covered by and will likely void the 6-month limited warranty that comes with X-Carve.


Software


Can I import files from another program?

Yes, as long as your program can export standard G-Code, SVG, or DXF files, the X-Carve will work with other CAD/CAM software options.

Can I run Easel Pro on multiple machines?

Yes. With the Machine Profiles feature, you can move your computer from machine to machine.

Do I need Internet access to use Easel and X-Carve?

Internet access is required to load and save Easel projects. Internet access is not required to work with a project once loaded or to connect to your machine and carve a project. If you do make changes to an Easel project while working offline, you will need to re-connect to the Internet to save them before closing the tab/window that the project is running in.

Will I be automatically billed after my 3-year upgrade to Easel Pro runs out?

No, you will not be automatically billed. Instead, we will send you a reminder so you can update your payment method and avoid disrupting your subscription.

What happens to my Easel Pro account after 3 years?

When your 3 years of Easel Pro runs out, you will need to have a valid payment method stored on your account for it to renew. Otherwise, your account will become an Easel Free account. We do not delete or destroy any projects, so if that happens (accidentally or on purpose), you'll just need to enter a valid payment method to be restored to an Easel Pro experience again.

Can I test out Easel Pro before purchasing the X-Carve?

A free 30-day trial of Easel Pro can be accessed via sign up here.

What computer do I need to run the software and machine?

You’ll need a computer with the following specs: USB port, Internet connection, and Windows 7 or higher, Mac OS X 10.10 or higher, or Ubuntu Linux 18.04 or higher.


Shipping & Setup


What is included with my X-Carve order?

See the "What's Included" section for the list of items that come in the Inventables X-Carve bundle.

How many boxes does the new X-Carve ship in?

The fully loaded X-Carve ships in 4 boxes with a total weight of around 100 lbs.

How long does it take to assemble the X-Carve?

Most customers assemble their machine over the course of a few days, with a total time of around 16 hours. While building your Inventables X-Carve you will become familiar with each of its components and you’ll gain an understanding of how the machine works.


Billing



I need a different payment method (purchase order, split payments, etc.). What other options do you offer?


Please contact support@matterhackers.com to inquire about other payment methods we may accept.


What if I order and need to cancel?


Please email us at support@matterhackers.com or call us at (800) 613-4290 (Mon - Fri, 9AM - 5PM PST) and our Customer Success team will assist you with your order.


Do you offer discounts for purchasing multiple X-Carves?


Please contact support@matterhackers.com to inquire about any bulk purchase, EDU, military, government, etc. discounts we may offer on particular products.


When will my credit card be billed?


Your credit card will be billed once you place your order.


Where can this be shipped?


Currently we only ship to US addresses, including US territories and military bases.


Could I add an extended warranty later?


Extended warranties can be added no later than 10 months from the date of purchase for the X-Carve.
